*Siltumsūkņi Viessmann Vitocal 222-G 6,1kW

Code: 88041006
Article: Z013727

In stock: call

7395.48 €* * Colour of product and equipment may not correspond to the illustration If the item is not in stock, then the price is for information only and it can be changed. * Price with VAT
Add to cart Quantity: pcs
Product description

VITOCAL 222-G

Vitocal 222-G with large DHW cylinder.

The Vitocal 222-G compact heat pump offers high levels of DHW convenience thanks to its 170 l DHW cylinder, which is heated via an internal indirect coil.

Complete and extremely compact – the compact Vitocal 222-G heat pumps are fully equipped with all of the components required for DHW and central heating. With heating outputs of between 5.9 and 10.0 kW, they are designed for use in detached houses, and flow temperatures up to 60 °C mean they can also be used with conventional radiators.

Natural heat for modern detached houses

The Vitocal 222-G compact heat pumps are specifically designed for detached houses. With their extremely compact dimensions of just over 0.4 square metres, they take up only a small floor area. With integral DHW cylinder, brine and heating circuit pumps, plus a 3-way diverter valve, these compact appliances are quick and easy to install. They are offered in two different versions: The Vitocal 222-G which has a 170 l cylinder. Both heat pumps offer high DHW convenience.

Heating naturally – naturally cooling as well

The compact heat pumps can provide a pleasant climate in a low energy house, even on hot summer days. The natural cooling function brings cool underground temperatures into the home. For this, the Viessmann NC-Box is required as an accessory

Take advantage of these benefits

■ Compact brine/water heat pumps with heating outputs from 5.9 to 10.0 kW;
■ „Low operating costs through high coefficients of performance: COP to EN 14511 up to 4.3 (brine 0 °C/water 35 °C) (COP = coefficient of performance);
■ Maximum flow temperature: 60 °C;
■ „High DHW convenience through integral DHW cylinder with a 220 l capacity in the Vitocal 242-G;
■ Very quiet thanks to the sound-optimised appliance design with a sound power level of 43 dB(A) at 0/35 °C;
■ „Ready to connect, ex works;
■ „Easy handling through small footprint, reduced height and split casing;
■ „Easy installation through variable connection accessories;
■ Prepared for Smart Grid and utilisation of photovoltaic power generated on site;
■ Instantaneous heating water heater integrated as standard.
